US Full Pallet, Pallet Solutions

Pallet Footprint Bulk Shippers

Pallet Shippers with a Standard / US
or Euro pallet footprint

When transporting bulk product, moving product on Standard / US or Euro pallet just makes life easier.  Product can be loosed loaded into a shipper and then either be unpacked at it’s destination or go straight on to racking if it’s to be stored before use.

Choose from shippers that are either Standard / US or Euro Pallet footprint.  All pallet footprint shippers are designed to fit the cargo hold of wide-body aircraft (part no’s GPS-RHS & GPS-RHW also fit the cargo hold of narrow-body aircraft).

Get in touch about Pallet Footprint Bulk Shippers

Standard / US Pallet Footprint

SEE PRODUCTS

Shippers with external dimensions of 48” x 40” (approx. 120cm x 100cm)

Temperature range:

2 to 8°C | 2 to 25°C | 15 to 25°C | Frozen

Duration:

Up to 120 hours

Payload size:

Up to 506L

Euro Pallet
Footprint

SEE PRODUCTS

Shippers with external dimensions of 120cm x 80cm (approx. 47” x 31.5”)

Temperature range:

2 to 8°C | Frozen

Duration:

Up to 158 hours

Payload size:

Up to 604L

Standard / US Pallet Footprint Shippers

Solution Part
Number		 Temperature
Range		 Minimum
Duration (hrs)		 Payload (in) Payload (mm) External Dimensions (in) External Dimensions (mm) Payload
Volume (l) 		Manufacturing
Location
L W H L W H L W H L W H
Half Pallet Summer GPS-RHS Refrigerated 120 33 30 7.3 838 762 184 48 40 30 1219 1016 762 117.5 USA
Half Pallet Winter GPS-RHW Refrigerated 120 35 30 9 889 762 229 48 40 30 1219 1016 762 155 USA
Full Pallet Summer GPS-RFS Refrigerated 96 32 30 28 813 762 711 48 40 50 1219 1016 1270 441 USA
Full Pallet Winter GPS-RFW Refrigerated 120 32 30 28 813 762 711 48 40 50 1219 1016 1270 441 USA
ChillTech Cargo CHC476 Refrigerated 120 35 27.2 30.5 890 690 775 47.2 39.4 51 1200 1000 1295 475.9 Europe
Tall Pallet SPS-R Refrigerated 120 33 24 36 838 610 914 48 40 62 1219 1016 1575 484 USA
Tall Pallet SPS-CRT CRT 120 33 24 36 838 610 914 48 40 62 1219 1016 1575 484 USA
Tall Pallet SPS-F Frozen 120 33 24 36 838 610 914 48 40 62 1219 1016 1575 484 USA
AmbiTherm Cargo ATN506 CRT 31 35 27.2 32.5 890 690 825 47.2 39.4 51 1200 1000 1295 506.6 Europe
ChillTherm Cargo CTC506 Refrigerated 97 35 27.2 32.5 890 690 825 47.2 39.4 51 1200 1000 1295 506.6 Europe
ClimiTherm Cargo CLT506 CRT 120 35 27.2 32.5 890 690 825 47.2 39.4 51 1200 1000 1295 506.6 Europe

Questions? We’re here to help. Chat now.

Find Your Solution

Euro Pallet Footprint Shippers

Solution Part
Number		 Temperature
Range		 Minimum
Duration (hrs)		 Payload (in) Payload (mm) External Dimensions (in) External Dimensions (mm) Payload
Volume (l) 		Manufacturing
Location
L W H L W H L W H L W H
ChillTherm Global CTG131 Refrigerated 114 32.1 17.9 13.9 815 454 354 48.2 32 34.5 1224 812 877 131 Europe
ChillTherm Regional CTR142 Refrigerated 84 31.6 17.1 15.4 803 435 390 48.2 32 34.5 1224 812 877 142 Europe
ChillTherm Global CTG242 Refrigerated 120 32.1 17.9 25.8 815 454 655 48.2 32 49.3 1224 812 1175 242 Europe
ChillTherm Regional CTR266 Refrigerated 84 32.3 18.5 27.2 820 470 690 48.2 32 46.3 1224 812 1175 266 Europe
FreezeTherm FT396 Frozen 158 41.3 25.6 22.8 1050 650 580 48.2 32 34.5 1224 812 877 396 Europe
FreezeTherm FT604 Frozen 114 41.3 25.6 34.8 1050 650 885 48.3 32 46 1227 813 1169 604 Europe
